Plastic Automatic Disc Filter Systems

GENERAL SPECIFICATION

▪️Plastic Filter Type                          : Self Clean Disc (PSC)

▪️Filter Body Material                       :PA6GFR30

▪️Disc Material                                 : PP

▪️Collector Material                          : S235JR, SS304L, SS316L, PE

▪️Maximum Working Pressure           : 8 bar; 116 Psi

▪️Minimum Working Pressure            : 2 bar; 29 Psi

▪️Maximum Working Temperature     : 60° ; 140°F

▪️Backwash Operation Criteria          : Pressure Difference

▪️Control System                            : Manual, Electronic (AC/DC)

▪️Filtration Sensitivity                      : 20,50,100,130,200 μ (micron)

If the collector material is S235JR

▪️Painting Method                         : Electrostatic Powder Coating

▪️Painting Material                        : Epoxy Polyester

ADVANTAGES OF FLUSHCORE

Intelligent Backflushing: Dual-mode triggers (Pressure & Time) ensure cleaning only when necessary, saving water and energy in any application.

Scalable Control (Out-of-the-Box): Control up to 10 filter stations immediately with a single unit-no extra modules or expansion cards required. This simplifies installation and reduces initial costs.

Centralized Command: Consolidate the control of your entire filter bank into a single, compact, and user-friendly panel.

Universal Integration: Designed for seamless connection with control systems like SCADA.

Versatile Power Compatibility (AC/DC): Offers ultimate installation flexibility. Flushcore operates seamlessly on both standard AC grid power and low-voltage DC sources, making it the perfect solution for any size, regardless of the available power infrastructure.

Reduced Operational Costs: Drastically cut maintenance labor, extend the life of your filter media, and improve overall system efficiency.

Robust & Reliable: Features a durable design built to withstand demanding environments, from the factory floor to the open field.

WORKING PRINCIPLE

The Flushcore operates on a dual-trigger principle to provide intelligent and efficient filter backwashing. It automatically initiates a cleaning cycle based on whichever of two user-set conditions occurs first: a specific pressure differential or a pre-defined time interval. All settings, including the pressure threshold, time interval, and flush duration, are easily configured via a user-friendly interface. A manual backwash function provides operators with on-demand cleaning capability, ensuring complete control over the filtration system.
