Metal Fertilizer Tanks-10V
Review (0)
€0.00
Tax excluded
Product by order, delivery time to be confirmed, contact us before ordering.
Uncompromising Fertigation. Unmatched Durability.
The Aytok Metal Fertilizer Tank is the rugged choice for reliable nutrient delivery. It uses a simple pressure differential for effective, powerless fertigation, free of any moving parts. Its robust, specially coated steel construction is built to endure high pressure and physical stress, making it the definitive investment for long-term performance in the field.
GENERAL SPECIFICATION - 10V
▪️ Body Material : S235JR
▪️ Maximum Working Pressure : 8 bar; 116 Psi
▪️ Maximum Working Temperature : 60°C; 140°F
▪️ Painting Method : Electrostatic Powder Coating
▪️ Paint Coating Material : Epoxy-Polyester
CLEANING PROCESS
During the cleaning process, the remaining liquid and accumulated residues inside the tank are flushed out efficiently through the vale, ensuring the system is completely cleared and ready fo
WORKING PRINCIPLE
The fertilizer tank operates based on a pressure differential created by a throttling valve installed between the tank's inlet and outlet lines. To operate the system, the tank is first filled with fertilizer and sealed. Opening only the inlet valve allows high-pressure water to enter and dissolve the fertilizer. After a homogeneous miture is formed, the outlet valve is opened. The pressure difference then drives the fertilizer solution from the tank into the lower-pressure main line for distribution.
1060V
