Vertical Metal Screen Filter-LE

GENERAL SPECIFICATION

▪️ Body Material                          : S235JR

▪️ Screen Material                       : SS304L, PAGGFR30

▪️Maximum Working Pressure       : 8 bar; 116 Psi

▪️Maximum Working Temperature : 60°C; 140°F

▪️Filtration Sensitivity                  : 20-2000 yp (micron)

▪️Painting Method                       : Electrostatic Powder Coating

▪️Paint Coating Material               : Epoxy-Polyester

CLEANING PROCESS

Manual cleaning is required when the pressure differential, monitored by manometers, indicates that the filter is clogged. The process begins by shutting down the system and depressurizing the filter. The cover is then removed and the screen cartridge is extracted. The cleaning principle for a screen filter is direct: the screen is thoroughly cleaned with pressurized water to remove all accumulated debris. After cleaning, the cartridge is reinstalled, and the filter is returned to service.

WORKING PRINCIPLE

Water enters the filter and passes through a stack of discs. As it flows toward the outlet, contaminants gradually accumulate on the outer surface of these discs. This buildup creates a pressure difference between the inlet and outlet. To ensure proper performance, the filter must be cleaned by the time the pressure difference reaches 0,7 bar.
