Plastic Automatic Filter P-HF

GENERAL SPECIFICATION

▪️Body Material                              :  S235JR/ SS304L /SS316L

▪️Screen Material (Internal kit)        : SS304L, PA6GFR30

▪️Maximum Working Pressure          : 8bar ; 116Psi

▪️Minimum Working Pressure           : 2 bar ; 29Psi

▪️Maximum Working Temperature    : 60°C ; 140°F

▪️Back Wash Time                          : Time and Pressure Difference Setup

▪️Control System                            : Electronic (AC/DC)

▪️Filtration Sensitivity                     : 20-2000 µ (micron)

CLEANING PROCESS

The backwash sequence is triggered by either a preset pressure differential or a time interval. Upon activation, the control unit opens the discharge valve. Exposing this valve to atmospheric pressure creates a significant pressure drop, inducing a powerful reverse flow. This reverse flow drives a hydraulic turbine, which rotates the cleaning collector as a piston moves it linearly. The collector's nozzles generate a high-velocity suction, vacuuming accumulated debris from the inner screen and expelling it through the drainage pipe. This combined helical motion ensures a systematic and through cleaning of the entire screen surface. Once complete, the discharge valve closes and the collector returns to its home position, concluding the cycle. Crucially the main filtration process continues uninterrupted throughout this self-cleaning process.

WORKING PRINCIPLE

Water enters the filter and passes sequentially through a coarse and then a fine screen. As contaminants accumulate on the inner surface of the fine screen, a pressure differential is created between the inlet and outlet, A backwash cycle is automatically initiated based on one of two conditions: when this pressure differential reaches a predetermined setpoint, or after a preset time interval has elapsed, whichever occurs first.
